850nm 940nm 5mm Infrared Emitter and Receiver IR LED

FOB Reference Price:Get Latest Price
$0.03 - $0.05 / Pieces | 10000 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Type:
Lamp LED
Model Number:
WEJ563JC-T2A
Chip Material:
AlGaAs
Emitting Color:
Infrared led
Luminous Intensity:
.
Luminous Flux(lm):
.
Power Dissipation:
70
Viewing Angle(°):
70/30
Place of Origin:
Guangdong, China
Brand Name:
WEJ
Certification:
CE, RoHS
Forward Current:
50mA
Forward voltage:
1.1-1.2V
Peak wavelength:
940nm
Radiant Intensity:
12-16mW/Sr
Supply Ability
Supply Ability:
20000000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
1000pcs/bag
Port
FOB SHENZHEN
Lead Time :
Shipped in 4 days after payment

850nm 940nm 5mm Infrared Emitter and Receiver IR DIP LED

Product information
Packing:1000pcs/bag;0.3kgs/bag
Lead time:7-10days
Payment item:T/T in advance









940nm IR LED

ParameterSymbolValueUnit
Power dissipationPd70mW
DC Forward CurrentIf50mA
Peak Forward CurrentIfp1000mA
Reverse VoltageVr5V
Operating TemperatureTopr-25to+85
Storage TemperatureTstg-40to+100

Lead Solder TemperatureTsol260 for 5sec

ParameterSymbolConditionValueUnit
Min.Min.Max.
Forward voltageVfIf=50mA1.11.2---V
Forward voltageIeIf=50mA1216---mW/Sr
Peak wavelengthλpIf=20mA---940---nm
Reverse currentIrVr=5V------5μA



 940nm PD LED

ParameterSymbolValueUnit
Power dissipationPd150mW
Reverse VoltageVr5V
Operating TemperatureTopr-25to+85
Storage TemperatureTstg-40to+100

Lead Solder TemperatureTsol260 for 5sec

ParameterSymbolConditionValueUnit
Min.Min.Max.
Wavelength Of Peak SensitivityλpIf=50mA---940---nm
Reverse Light CurrentIL

Ee=1m W/cm2

λp=940nm

VR=5V
10---20uA
Reverse Dark CurrentID

Ee=0m W/cm2

VR=10V
---530nA
Reverse Breakdown VoltageVBR

Ee=0m W/cm2

IR=100µA
33170---V
Viewing Angle θ

X

707590°
  Y304045°
